Html5 Canvas 所有的畫線指令畫出來的線條都有毛邊（比如 lineTo， arcTo，strokeRect），這是因為在Canvas中整數坐標值對應的位置恰巧是屏幕象素點中間的夾縫，那么當按這樣的坐標進行線條渲染時所要用到的就是夾縫兩邊的象素點，這樣即便設置了lineWidth為1也將看到兩個象素效果的線條，解決方法原象素點+0.5進行偏移。
<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01//EN" "http://www.w3.org/TR/html4/strict.dtd">
<html>
<head>
<meta http-equiv="Content-Type" content="text/html; charset=utf-8">
<title>canvasTest</title>
<script type="text/javascript" src="http://www.pyzy.net/Demo/html5_cancas_js/excanvas.js"></script>
<script type="text/javascript">
var MyCanvas = function(boxObj, width, height) {
//序號、計數
this.index = arguments.callee.prototype.Count = (arguments.callee.prototype.Count || 0) + 1;
var cvs = document.createElement("canvas");
cvs.id = "myCanvas" + this.index;
cvs.width = width || 800;
cvs.height = height || 600;
(boxObj || document.body).appendChild(cvs);
//excanvas框架中針對ie加載canvas延時問題手動初始化對象
if (typeof G_vmlCanvasManager != "undefined") G_vmlCanvasManager.initElement(cvs);
//2D畫布對象
this.ctx = cvs.getContext("2d");
/* * 繪制線條
* @ops JSON對象，可按實際支持屬性擴展，示例： { lineWidth:1,strokeStyle:'rgb(255,255,255)' }
* @dotXY:{ x:0, y:0 } ||[{ x:0, y:0 },{ x:0, y:0 }]
*/
this.drawLine = function(dotXY, ops) {
this.ctx.beginPath();
for (var att in ops) this.ctx[att] = ops[att];
dotXY = dotXY.constructor == Object ? [dotXY || { x: 0, y: 0}] : dotXY;
this.ctx.moveTo(dotXY[0].x, dotXY[0].y);
for (var i = 1, len = dotXY.length; i < len; i++) this.ctx.lineTo(dotXY[i].x, dotXY[i].y);
this.ctx.stroke();
};
};
window.onload=function(){
var c1 = new MyCanvas();
c1.drawLine([{ x: 10, y: 10 }, { x: 10, y: 200 }],{lineWidth:2,strokeStyle:'rgb(0,0,0)'});
c1.drawLine([{ x: 11, y: 10 }, { x: 11, y: 200 }],{lineWidth:2,strokeStyle:'rgb(255,255,255)'});
c1.drawLine([{ x: 100, y: 10 }, { x: 100, y: 200 }],{lineWidth:1,strokeStyle:'rgb(0,0,0)'}); //普通線
c1.drawLine([{ x: 200.5, y: 10 }, { x: 200.5, y: 200 }],{lineWidth:1,strokeStyle:'rgb(0,0,0)'}); //+0.5偏移
}
</script>
</head>
<body>
↓ 處理的 ↓ 普通的 ↓ +0.5偏移的<br />
</body>
</html>
